Subwoofer Box JBL STAGE 810

Ported Box for 8 inch Subwoofer


8 inch subwoofer box JBL STAGE 810

Subwoofer Box Specifications

Enclosure Name: STAGE 810

Subwoofer Brand: JBL

Subwoofer Size: 8 inch

Subwoofer Count: 1

Box External Dimensions
Width × Height × Depth
13.39" × 9.84" × 9.26"
Material Thickness 0.79"
Net Internal Volume 0.42 ft3
Tuning Frequency 50 Hz
Port Area 3.0 inch2
Pipe Inner Diameter 1.97"
Pipe Length 5.80"


Detail Size Quantity
Top / Bottom 13.39" × 9.26" 2
Front / Rear 13.39" × 8.27" 2
Left / Right 7.68" × 8.27" 2
Ø54mm Ø178.4mm 13.39" 9.26" 7.68" 9.26" 7.68" 9.84" 8.27" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
