Box External Dimensions Width × Height × Depth |
30.00" × 18.00" × 18.59" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 40 inch2 |
| Port Inlet Width × Height |
2.43" × 16.50" |
| Port Length | 18.58" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 30.00" × 18.59" | 2 |
| Front | 26.83" × 16.50" | 1 |
| Rear | 30.00" × 16.50" | 1 |
| Left | 17.09" × 16.50" | 1 |
| Right | 17.84" × 16.50" | 1 |
| Port | 13.92" × 16.50" | 1 |
