Box External Dimensions Width × Height × Depth |
40.00" × 17.00" × 12.98" |
| Material Thickness | 1.00" |
| Net Internal Volume | 2.70 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 45 inch2 |
| Port Inlet Width × Height |
3.00" × 15.00" |
| Port Length | 28.44" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 40.00" × 12.98" | 2 |
| Front | 36.00" × 15.00" | 1 |
| Rear | 40.00" × 15.00" | 1 |
| Left | 10.98" × 15.00" | 1 |
| Right | 11.98" × 15.00" | 1 |
| Port | 7.98" × 15.00" | 1 |
| Port | 15.46" × 15.00" | 1 |
