Subwoofer Box Specifications
Enclosure Name: 10 ГД-30
Subwoofer Size: 8 inch
Subwoofer Count: 1
|
Box External Dimensions Width × Height × Depth |
19.69" × 9.84" × 12.13" |
| Material Thickness | 0.63" |
| Net Internal Volume | 0.92 ft3 |
| Tuning Frequency | 38 Hz |
| Port Area | 6.2 inch2 |
| Port Inlet Width × Height |
0.72" × 8.58" |
| Port Length | 9.51" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 19.69" × 12.13" | 2 |
| Front | 18.33" × 8.58" | 1 |
| Rear | 19.69" × 8.58" | 1 |
| Left | 10.87" × 8.58" | 1 |
| Right | 11.50" × 8.58" | 1 |
| Port | 8.88" × 8.58" | 1 |
