Box External Dimensions Width × Height × Depth |
23.62" × 13.78" × 13.61" |
| Material Thickness | 0.63" |
| Net Internal Volume | 1.41 ft3 |
| Tuning Frequency | 38.5 Hz |
| Port Area | 24.8 inch2 |
| Port Inlet Width × Height |
1.98" × 12.52" |
| Port Length | 25.82" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 23.62" × 13.61" | 2 |
| Front | 21.01" × 12.52" | 1 |
| Rear | 23.62" × 12.52" | 1 |
| Left | 12.35" × 12.52" | 1 |
| Right | 12.98" × 12.52" | 1 |
| Port | 10.37" × 12.52" | 1 |
| Port | 12.21" × 12.52" | 1 |
