Box External Dimensions Width × Height × Depth |
42.00" × 18.00" × 28.86" |
| Material Thickness | 0.71" |
| Net Internal Volume | 9.00 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 120 inch2 |
| Port Inlet Width × Height |
7.24" × 16.58" |
| Port Length | 17.70" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 42.00" × 28.86" | 2 |
| Front | 34.06" × 16.58" | 1 |
| Rear | 42.00" × 16.58" | 1 |
| Left | 27.44" × 16.58" | 1 |
| Right | 28.15" × 16.58" | 1 |
| Port | 16.99" × 16.58" | 1 |
