Box External Dimensions Width × Height × Depth |
19.69" × 12.99" × 12.72" |
| Material Thickness | 0.59" |
| Net Internal Volume | 1.41 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 7.8 inch2 |
| Port Inlet Width × Height |
0.66" × 11.81" |
| Port Length | 8.67" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 19.69" × 12.72" | 2 |
| Front | 18.44" × 11.81" | 1 |
| Rear | 19.69" × 11.81" | 1 |
| Left | 11.54" × 11.81" | 1 |
| Right | 12.13" × 11.81" | 1 |
| Port | 8.07" × 11.81" | 1 |
