Box External Dimensions Width × Height × Depth |
21.65" × 13.39" × 16.16" |
| Material Thickness | 0.79" |
| Net Internal Volume | 1.59 ft3 |
| Tuning Frequency | 36 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.97" × 11.81" |
| Port Length | 24.52" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 21.65" × 16.16" | 2 |
| Front | 18.90" × 11.81" | 1 |
| Rear | 21.65" × 11.81" | 1 |
| Left | 14.58" × 11.81" | 1 |
| Right | 15.37" × 11.81" | 1 |
| Port | 12.61" × 11.81" | 1 |
| Port | 8.36" × 11.81" | 1 |
