Box External Dimensions Width × Height × Depth |
21.65" × 16.38" × 22.06" |
| Material Thickness | 0.71" |
| Net Internal Volume | 2.90 ft3 |
| Tuning Frequency | 21 Hz |
| Port Area | 21 inch2 |
| Port Inlet Width × Height |
1.41" × 14.96" |
| Port Length | 38.64" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 21.65" × 22.06" | 2 |
| Front | 19.54" × 14.96" | 1 |
| Rear | 21.65" × 14.96" | 1 |
| Left | 20.64" × 14.96" | 1 |
| Right | 21.35" × 14.96" | 1 |
| Port | 19.23" × 14.96" | 1 |
| Port | 16.58" × 14.96" | 1 |
