Box External Dimensions Width × Height × Depth |
35.00" × 15.00" × 6.58" |
| Material Thickness | 0.63" |
| Net Internal Volume | 1.20 ft3 |
| Tuning Frequency | 40 Hz |
| Port Area | 17 inch2 |
| Port Inlet Width × Height |
1.24" × 13.75" |
| Port Length | 18.80" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.00" × 6.58" | 2 |
| Front / Rear | 35.00" × 13.75" | 2 |
| Left | 5.33" × 13.75" | 1 |
| Right | 3.46" × 13.75" | 1 |
| Port | 18.80" × 13.75" | 1 |
