Box External Dimensions Width × Height × Depth |
28.00" × 14.00" × 21.24" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.75 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 40 inch2 |
| Port Inlet Width × Height |
3.20" × 12.50" |
| Port Length | 30.52" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 28.00" × 21.24" | 2 |
| Front | 24.05" × 12.50" | 1 |
| Rear | 28.00" × 12.50" | 1 |
| Left | 19.75" × 12.50" | 1 |
| Right | 20.50" × 12.50" | 1 |
| Port | 16.55" × 12.50" | 1 |
| Port | 9.28" × 12.50" | 1 |
