Box External Dimensions Width × Height × Depth |
48.00" × 9.00" × 7.32" |
| Material Thickness | 0.75" |
| Net Internal Volume | 0.86 ft3 |
| Tuning Frequency | 33 Hz |
| Port Area | 11 inch2 |
| Port Inlet Width × Height |
1.46" × 7.50" |
| Port Length | 27.52" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 48.00" × 7.32" | 2 |
| Front | 45.79" × 7.50" | 1 |
| Rear | 48.00" × 7.50" | 1 |
| Left | 5.83" × 7.50" | 1 |
| Right | 6.57" × 7.50" | 1 |
| Port | 4.36" × 7.50" | 1 |
| Port | 20.20" × 7.50" | 1 |
