Box External Dimensions Width × Height × Depth |
28.35" × 16.54" × 16.05" |
| Material Thickness | 0.63" |
| Net Internal Volume | 3.18 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 31 inch2 |
| Port Inlet Width × Height |
2.03" × 15.28" |
| Port Length | 14.65" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 28.35" × 16.05" | 2 |
| Front | 25.69" × 15.28" | 1 |
| Rear | 28.35" × 15.28" | 1 |
| Left | 14.79" × 15.28" | 1 |
| Right | 15.42" × 15.28" | 1 |
| Port | 12.13" × 15.28" | 1 |
