Box External Dimensions Width × Height × Depth |
30.00" × 30.00" × 10.76" |
| Material Thickness | 0.75" |
| Net Internal Volume | 3.75 ft3 |
| Tuning Frequency | 33 Hz |
| Port Area | 42 inch2 |
| Port Inlet Width × Height |
1.47" × 28.50" |
| Port Length | 19.79" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 30.00" × 10.76" | 2 |
| Front / Rear | 30.00" × 28.50" | 2 |
| Left | 9.26" × 28.50" | 1 |
| Right | 7.04" × 28.50" | 1 |
| Port | 19.79" × 28.50" | 1 |
