Box External Dimensions Width × Height × Depth |
12.00" × 12.00" × 12.11" |
| Material Thickness | 0.63" |
| Net Internal Volume | 0.60 ft3 |
| Tuning Frequency | 40 Hz |
| Port Area | 8 inch2 |
| Port Inlet Width × Height |
0.74" × 10.74" |
| Port Length | 18.98" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 12.00" × 12.11" | 2 |
| Front | 10.63" × 10.74" | 1 |
| Rear | 12.00" × 10.74" | 1 |
| Left | 10.85" × 10.74" | 1 |
| Right | 11.48" × 10.74" | 1 |
| Port | 10.10" × 10.74" | 1 |
| Port | 6.87" × 10.74" | 1 |
